n8n Webhook AI Mapper: Merge JSON Datasets via Mapping API

Merge two JSON datasets automatically—using AI mapping to unify fields via an n8n Webhook

The n8n Webhook AI Mapper: Merge JSON Datasets via Mapping API accepts Dataset A and Dataset B through a webhook, profiles their schemas, calls an external AI mapping API to infer field correspondences, then transforms and merges the data into a single unified dataset—returning both mapping confidence scores and a full audit report as JSON.

What this workflow does

• Receives a POST webhook request containing Dataset A, Dataset B, and optional mapping hints or a target schema.
• Validates and profiles both datasets by extracting field types and sampling rows to understand structure.
• Calls an external AI mapping API (via HTTP) with the schema profiles and samples to request suggested source-to-target field mappings.
• Normalizes mapping results into a clean mapping list with confidence scores, and falls back to heuristic field-name matching if the AI response is missing or unusable.
• Builds transformation rules from the mappings, reshapes Dataset A into the target field structure, then merges the transformed Dataset A rows with the original Dataset B rows.
• Returns a JSON response that includes the merged dataset, mapping report (statistics and low-confidence mappings), and request metadata.

Use cases

• Unifying CRM/export data where field names and types differ across systems.
• Consolidating product catalogs or user records from two JSON sources into one consistent schema.
• Building an API-style ingestion endpoint that produces traceable mapping confidence for downstream processing.

Technical details

• Nodes / components: webhook, http request, code, wait, respond to webhook, sticky note.
• External dependency: an AI mapping/LLM endpoint over HTTP (the workflow currently shows https://httpbin.org/post as a placeholder to replace with your real mapping API URL).

Great for: n8n users and automation engineers who need reliable JSON dataset merging with transparent mapping quality and an audit trail.
